GEO Precision lasers are the result of decades of experience in the research, development, and production of construction lasers. The design, the materials used, as well as our rigorous quality assurance process are guarantors of high functionality and a long service life. All our devices are designed and manufactured exclusively in Germany and are renowned worldwide for their perfection in terms of handling, precision, robustness, and quality.



• Performance features
  Laser class 2, laser power < 1 mW. No special safety precautions necessary. The easy standard laser class.

• Fully automatic
  Automatic levelling and cut-out in case of low battery or jerky movements.

• Automatic function can be switched off
  Therefore inclination adjustment by points of reference is possible.

• Illuminated, clearly legible LCD display
  Self-explanatory, for on/off, device data, company data, lock function, operating status, battery level and menu.

• Increased safety
  Control indicators with blinking warning system for levelling, operating status and low battery.


• Robust metal housing
  Plastic coated, swept and filled with nitrogen, 100 % watertight.

• Special laser beam quality
  Diode laser with visible beam, high-powered lens, high life expectancy and low power consumption.

• Lithium ion rechargeable battery
  Operation time to 28 hours with one charge. Rechargeable in max. 5 hours without having to take out the battery.

• Uncompromisingly easy
  All you have to do is switch on/off. The rest is done by the PL-74L automatically.

• Checking and adjustment
  Easily possible at the building site as well. The device does not have to be opened for adjustment.





Application Examples

Automobile Industry & Industrial Applications Levelling, aligning, measuring: Being able to carry out these tasks quickly and accurately results in successful and cost-efficient performance, whether in aviation, shipbuilding, and railcar construction, or in the manufacture and setup of machinery of any kind.

Roll Alignment A number of industrial applications require precise roll alignment in terms of both height and direction.

Structural Monitoring / Automatic Traversing Whether snow load measuring on roofs, subsidence measuring of buildings, monitoring of soil injection and tunnel construction, structure relocation, bridge renovation, or automatic traversing.

Track Surveying Tracks provide guidance in a broad range of technical applications, from classic railway tracks and crane rails to positioning systems. All of them, however, have one thing in common: Direction, height, and distance have to fit together within very small tolerances.
