Leica Rod Eye 140 - Classic Receiver
Leica Rod Eye 140 - Classic Receiver
    Leica Rod Eye 140 - Classic Receiver
Leica Rod Eye 140 - Classic Receiver

About

Product Details

The classic receiver is equipped with two sizable graphic displays on both its front and back for clear visibility. It includes a level vial to guarantee precise alignment and enhance measurement accuracy. Additionally, it offers anti-strobe protection to filter out interference from intense strobe lights on site. With an IP67 rating, this receiver is both dustproof and water-resistant, making it highly reliable for demanding outdoor environments.



Features

  • LCD indication
  • Level vial
  • Anti-strobe protection
  • Grade rod bracket
  • Built-in 4.7" (12 cm) detection window



Applications

  • Surveying and Construction

Specifications
Working Diameter (Laser Dependent) 4,429.13' (1,350 m)
Detection Window 4.72" (120 mm)
Detectable Spectrum 600 to 800 nm
Automatic Shutoff 10 minutes
Audio Volumes High/Low/Off
Arrow Display 9 channels
Detection Accuracies Fine: ±1 mm; medium: ±2 mm; coarse: ±3 mm
Protection Class IP67
Operating Temperature -4 to 122°F (–20 to 50°C)
MPN 789923
Product Details

The classic receiver is equipped with two sizable graphic displays on both its front and back for clear visibility. It includes a level vial to guarantee precise alignment and enhance measurement accuracy. Additionally, it offers anti-strobe protection to filter out interference from intense strobe lights on site. With an IP67 rating, this receiver is both dustproof and water-resistant, making it highly reliable for demanding outdoor environments.



Features

  • LCD indication
  • Level vial
  • Anti-strobe protection
  • Grade rod bracket
  • Built-in 4.7" (12 cm) detection window



Applications

  • Surveying and Construction

Specifications
Working Diameter (Laser Dependent) 4,429.13' (1,350 m)
Detection Window 4.72" (120 mm)
Detectable Spectrum 600 to 800 nm
Automatic Shutoff 10 minutes
Audio Volumes High/Low/Off
Arrow Display 9 channels
Detection Accuracies Fine: ±1 mm; medium: ±2 mm; coarse: ±3 mm
Protection Class IP67
Operating Temperature -4 to 122°F (–20 to 50°C)
MPN 789923
Leica Geosystems Leica Geosystems

LE-789923

Leica Rod Eye 140 - Classic Receiver

$345.00
$345.00
Shipping calculated at checkout.
The classic receiver has 2 large graphic displays on the front and back of the receiver. It features a level vial that ensures g...  Read more
The classic receiver has 2 large graphic displays on the front and back of the receiver. It features a level vial that ensures good alignment and improves reading accuracy. It also has anti-strobe protection that detects and ignores the flash from strong strobes on the job. The classic receiver has an IP67 rating, making it dustproof and water-resistant, perfect for outdoor use.
Free Shipping Available

Free Shipping on Levels, Lasers, Locators, Total Stations and Digital Theodolites
