Product Details

Robust IP65 housing with front and back side display, incl. Magnets for ceiling attachment. Locating red and green laser beams at distances up to 80 m.

Compatibility: Leica Lino L2, L2G, L2P5, L2P5G, L6R, L6G

Dimensions: 158 x 73 x 26 mm

Article number: 866090

Features
  • Increase range of Line Laser to 80 m
  • Works with L2, L2G, L2P5, L2P5G, L6R, L6G, L4P1
  • Large detecting area
  • Supports red as well as green laser models
  • Acoustic feedback
  • Two illuminated displays to allow reading from backside
Specifications
Working range 2 m – 80 m (6.6 ft – 262 ft)
Accuracy (switchable) ± 1.0 mm (± 0.04 in) / ± 3.0 mm (± 0.12 in)
Detection window 85 mm (3.3 in)
Detection angle 130°
Detectable spectrum 635 ± 5 nm (red) / 525 ± 5 nm (green) class 2 acc. IEC 60825-1
Illuminated display front side and back side
Acoustical signal 100 dB / 80 dB / 0 dB
Protection class IP65 (IEC 60529) dust and jet water
Drop resistance 1.2 m (3.9 ft)
Battery type/life 2 x AA 1.5 V / 40+ hours
Low power alert digital display
Dimensions (L x W x H) 158 x 73 x 26 mm (6.22 x 2.87 x 1.02 in)
Weight with batteries 250 g (0.55 lbs)
Automatic shut-off 30 min without detection
Operating temperature -10… +50 °C (+14… +122 °F)
Storage temperature -25… +70 °C (-13… +158 °F)
Documents
Leica RGR 200 Line laser Receiver -Red and Green laser lines Datasheet
Datasheet
Leica Geosystems | 866090

Leica RGR 200 Line laser Receiver -Red and Green laser lines

Includes: RGR 200, Quick start guide, rugged receiver bracket, 2 AA
Includes: RGR 200, Quick start guide, rugged receiver bracket, 2 AA
$240.00
$240.00
Shipping calculated at checkout.
Pickup available at KARA Co. Typically ready within 24 hours.
