Includes

Theodolite
NiMh Rechargeable Battery Pack/Charger
Alkaline Batterie Pack
Tool Kit
Rain Hood
Plumb Bob and Carrying Case
Manual

TECHNICAL DATA	DT8-05P	DT8-05LP	DT8-05LS
Telescope – Objective aperture	1.77 in (45 mm)	1.77 in (45 mm)	1.77 in (45 mm)
Magnification	30X	30X	30X
Image	Erect	Erect	Erect
Field of view	1° 30'	1° 30'	1° 30'
Resolution	3”	3”	3”
Minimum focus	53 in (1.3 m)	53 in (1.3 m)	53 in (1.3 m)
Stadia constant	100	100	100
Angle measurement	Absolute Encoding	Absolute Encoding	Absolute Encoding
Minimum reading	1” / 5”	1” / 5”	1” / 5”
Direction method	H: Both sides V: Single side	H: Both sides V: Single side	H: Both sides V: Single side
Accuracy	5”	5”	5”
Unit of angle	Deg / mil / gon / V%	Deg / mil / gon / V%	Deg / mil / gon / V%
Display	LCD both sides	LCD both sides	LCD both sides
Automatic compensation	Yes	Yes	Yes
Range of compensation	±3’	±3’	±3’
Plummet type	Optical	Laser	Optical
Plummet magnification	3X	–	3X
Plummet field of view	5°	–	5°
Focusing range	20 in to ∞ (0.5 m to ∞)	–	20 in to ∞ (0.5 m to ∞)
Reticle type	Crosshair	–	Crosshair
Laser power	–	≤ 1 mW	–
Facular diameter	–	≤ 2 mm	–
Centering precision	1.5 mm (instrument height 1.5 m)
Plate vial sensitivity	30” per 2 mm	30” per 2 mm	30” per 2 mm
Circular vial sensitivity	8’ per 2 mm	8’ per 2 mm	8’ per 2 mm
Operating voltage (typical)	4.8 VDC	4.8 VDC	4.8 VDC
Batteries	4 × AA / Rechargeable Ni-MH	4 × AA / Rechargeable Ni-MH	4 × AA / Rechargeable Ni-MH
Operating temperature	-4 °F to +122 °F (-20 °C to +50 °C)	-4 °F to +122 °F (-20 °C to +50 °C)	-4 °F to +122 °F (-20 °C to +50 °C)
Waterproof class	IP54	IP54	IP54
Weight	10.2 lb (4.6 kg)	10.2 lb (4.6 kg)	10.2 lb (4.6 kg)
Dimensions	6.5 × 6.1 × 13.4 in (164 × 154 × 340 mm)	6.5 × 6.1 × 13.4 in (164 × 154 × 340 mm)	6.5 × 6.1 × 13.4 in (164 × 154 × 340 mm)
